Hydraulic Cylinder 74-98-167 Plaga 166,75 Clausa 56,25 Rod Pin 2 Rod Latitudo 2 Base Pin 2 LMSD 7 Gradus 4 Plaga 166 Extensus 405
Cylindrus Hydraulicus 74-98-167 ex HCIC fabricatur cum certa qualitate pro applicationibus hydraulicis quotidie mobilibus et industrialibus. Signa ISO aedificata 9001:2015 signa, haec cylindrus observantiam constantem tradit.
Quaelibet unitas est praecisio-machina et pressio 100% ante probata sit amet. Aliquam pretium cursus magna.
| Pars Number | 74-98-167 |
| Type | Geminus-Agens |
| Opus Pressura | 2,500 – 3,500 PSI |
| Type sigillum | Summus perficientur polyurethane |
Hydraulic Cylinder 74-98-167
Numero graduum 4
Maximum movens Scaena Diameter VII pollices
Plaga Longitudo (A) 166.06 in (4218 mm)
Clausa Longitudo (B) 56.25 in (1429 mm)
Longitudo extensa (C) 222.31 in (5647 mm)
Rod Mount Width (D) 2 in (51 mm)
Rod Mount Pin Hole (E) 2.06 in (52 mm)
Basi Mons Latitudo (G) 8.63 in (219 mm)
Base Mount Pin Hole (J) 2.13 in (54 mm)
Portus (L) 1" NPTF
Olei metrete (Retracted) 3.7
Olei metrete (Extended) 17.5
