Snowplow Cylindri: 1.5″ Bore, 12″ Stroke, 1.25″ Rod
The Snowplow Cylinder 1.5" Bore x 12" Stroke x 1.25" Virga ab HCIC speciatim designata est ad laminas niveas positiones et applicationes anglicas. Haec duplex agens hydraulica cylindrici certas in tempestatibus frigoris condiciones certas praebet.
Cum sigillis tempestatis frigoris aedificata et praesidio corrosio provecta, hoc cylindrum machinatum est propter condiciones hiemis nivis remotionis graves. Quaelibet unitas 100 pressura probata ante sit amet.
HCIC tribuit nives cylindros omnibus majoribus nivis faces.
| Bore Diameter | 1.5 pollices |
| Longitudo plaga | XII pollices |
| Rod Diameter | 1.25 pollices |
| Type | Geminus-Agens |
| Opus Pressura | 2,500 – 3,000 PSI |
| Type sigillum | Frigus-tempestas rated |
Actio: Single-Acting
Bore (ID): 1.5″
Plaga: 12″
Rod (OD): 1.25″
Adscendens Type: foramen
Adscendens Pin (OD): 1″
Virga finis Type: foramen
Rod End Pin (OD): 1″
Opus Portuum: 1/4″ NPT(F)
Max Operationis Impetus: 3,000 PSI
Retractavit Longitudo: 19.25″ (pin ad pin, centrum in centro)
Longitudo extensa: 31.25″ (pin ad clavum, centrum in centro)
Cylindrus Longitudo: 20.75″ (retractata ora ad marginem)
Columna Load: 5306 lbs
Product pondus: 15.6 pondo
Ferrum materiale: ferrum exstinctum et temperatum (ASIS 1020)
Rod Materia: Terra distrahens et polita chrome patella ferro (ASIS 1045)
Glandula Materia: Princeps distrahens nodulosus ferrum (ASTM A536 gradus 70-50-05)
Piston Material: High distrahentes nodulares ferrum (ASTM A536 gradus 70-50-05)
